Cara Setting ONT di OLT ZTE C320
Cara
Setting ZTE C320
Default username
: zte Password : zxr10
Hyperterminal :
Baud rate 9600, Data bit 8, parity None, Stop bits 1, Flow control None
Enable password
: zxr10
1. Adding
Rack
ZXAN#conf
t
Enter
configuration commands, one per line.
End with CTRL/Z.
ZXAN(config)#add-rack
rackno 1 racktype C320Rack
ZXAN(config)#show
rack
Rack RackType SupShelfNum CfgShelfNum
-------------------------------------------------------------------------------
1 C320Rack 1 0
2. Adding
shelf
ZXAN(config)#add-shelf
shelfno 1 shelftype C320_SHELF
ZXAN(config)#show
shelf
Rack Shelf
ShelfType ConnectId CleiCode Serial-Number
---------------------------------------------------------------------------------
1 1
C320_SHELF 0 UnKnowCleiCode 702401300041
ZXAN(config)#
3. Adding
Daughter-Card
ZXAN(config)#add-subcard
slotno 4 subcardno 1 UCDC/1
ZXAN(config)#sho
subcard
Rack
Shelf Slot Sub CfgType RealType Status
-------------------------------------------------------------------------------
1 1
4 1 UCDC/1
UCDC/1 INSERVICE
ZXAN(config)#
4. Adding
Card
ZXAN#show
card
Rack
Shelf Slot CfgType RealType Port
HardVer SoftVer Status
-------------------------------------------------------------------------------
1 1
1 GTGOG N/A
120301 V1.2.5P3 HWONLINE
1 1
3 PRAM PRAM
3 V1.01 INSERVICE
1 1
4 SMXA SMXA
3 110702 V1.2.5P3 INSERVICE
ZXAN(config)#add-card
slotno 1 GTGO
ZXAN(config)#show
card
Rack
Shelf Slot CfgType RealType Port
HardVer SoftVer Status
-------------------------------------------------------------------------------
1 1
1 GTGO GTGOG
8 120301 V1.2.5P3 INSERVICE
1 1
3 PRAM PRAM
3 V1.01 INSERVICE
1 1
4 SMXA SMXA
3 110702 V1.2.5P3 INSERVICE
5. Creating
Username and Password
ZXAN(config)#service
password-encryption
ZXAN(config)#username
test password test privilege 15
ZXAN#show
username
Username Password Privilege Max-sessions
zte dnXspUMqxfJOgln2Hm7Olw==
supervisor 16
noc pP2Ob6n7+abyyZ57cKqe8g==
supervisor 16
test test supervisor
6. Configuring
ONU
ZXAN(config)#pon
ZXAN(config-pon)#onu-type
G210 gpon description 1GE,1FE,1POTS max-tcont 7 max-gemport 32
max-switch-perslot 1 max-flow-perswitch 32
ZXAN(config-pon)#onu-type-if
G210 eth_0/1-2
ZXAN(config-pon)#onu-type-if
G210 pots_0/1
ZXAN(config-pon)#show
onu-type gpon G210
Onu
type name: G210
Pon
type: gpon
Description: 1GE,1FE,1POTS
Max
tcont: 7
Max
gemport: 32
Max
switch per slot: 1
Max
flow per switch: 32
Max
iphost: 2
Service
ability N:1: support
Service
ability 1:M: support
Service
ability 1:P: support
WiFi
mgmt via non OMCI: disable
Omci
send mode: async
Default
multicast range: none
ZXAN(config-pon)#
7. Authenticating
ONU
ZXAN(config)#show
gpon onu uncfg gpon-olt_1/1/1
OnuIndex Sn State
---------------------------------------------------------------------
gpon-onu_1/1/1:1 XPON98607839 unknown
ZXAN(config)#interface
gpon-olt_1/1/1
ZXAN(config-if)#onu
1 type G210 sn XPON98607839
ZXAN(config-if)#show
gpon onu uncfg gpon-olt_1/1/1
%Code
32310-GPONSRV : No related information to show.
ZXAN(config-if)#show
gpon onu state gpon-olt_1/1/1
OnuIndex Admin State OMCC State
O7 State Phase State
----------------------------------------------------------------------------
gpon-onu_1/1/1:1 enable enable operation working
ONU
Number: 1/1
8. Setting
ONU and Port
ZXAN(config)#
interface gpon-onu_1/1/1:1
ZXAN(config-if)#
tcont 1 name test profile 100M
ZXAN(config-if)#
gemport 1 unicast tcont 1 dir both
ZXAN(config-if)#
switchport mode hybrid vport 1
ZXAN(config-if)#
service-port 1 vport 1 user-vlan 7 vlan 7
ZXAN(config-if)#
exit
ZXAN(config)#
pon-onu-mng gpon-onu_1/1/1:1
ZXAN(config-if)#
service test gemport 1 vlan 7
ZXAN(config-if)#
vlan port eth_0/1 mode tag vlan 7
ZXAN(config-if)#exit
9.
